Semi-Auto Dual Axis SolarTracking Mount
Key words:
Flat Single Solar Tracking Mount
Semi-Auto Dual Axis SolarTracking Mount
Semi-Auto Dual Axis Solar Tracking Mount
Classification:
- Product Description
- Product Parameters
-
Product Introduction:
Elevate your solar power generation with our Discount Wholesale Semi-Auto Dual Axis SolarTracking Mount on sales, a cutting-edge solution designed for optimal performance with two-sided modules. Our Semi-Auto Dual Axis SolarTracking Mount suppliers in China have developed a system that ensures the back of bifacial modules remains unobstructed, maximizing power output and compatibility with all commercial PV modules available in the market.
With a focus on resilience, our mount boasts high frame strength for superior wind resistance, ensuring the stability of the system even in strong wind conditions. The unipolar support structure provides the best terrain adaptability, making it an ideal choice for various landscapes. The simple structure of our Semi-Auto Dual Axis SolarTracking Mount makes installation and maintenance a breeze, saving you time and effort.
Intelligent control is at the heart of our system, with self-positioning and self-calibration capabilities that come at a low cost. The innovative rain cleaning mode effectively reduces the time spent on cleaning solar panels, while the snow mode increases power generation time during winter months. Our mount is designed to not interfere with plant growth, ensuring that the ecosystem around the installation remains undisturbed.
lt is our patent structure with automatic tracking in the east-west direction and manual adjustment for elevation angle. lt realized high power generation efficiency at the lowest cost and improved system stability, reduced failure rate. Better terrain adaptability with independent support structure. lmprove your power generation by 25%-35% .
System FeaturesThe best solution for two sided modules
This system ensures that the back of the bifacial modules is unobstructed, maximizes power generation, and is compatible with all commercial PV modules on the market.
Stronger wind resistance
High frame strength - better wind resistance, which can ensure the stability of the system operation in strong wind weather.
Better terrain adaptability
Unipolar support structure - optimal terrain adaptability.
Easier to install and maintain
Simple structure, easy to install and maintain.
intelligent control
self-positioning and self - calibration with low costs.
Rain cleaning mode - effectively reduce the cleaning time of solar panels. Snow mode - effectively increase your power generation time.
does not affect plant growth
No constant sun or rain cover-no effect on plant growth.
Product Application
-
Basic parameters of the system Tracking type Independent Drive No. of panel
2-10pcs (≤23m2)
Motor DC 24V/1.5A X1 Power consumption 3.0 kw.h/set/year Max. wind speed in running 24m/s Max. wind speed in flat 40m/s Rust protection Hot-dipped galvanized/superdyma Elevation angle range 45° Control model Time + GPS control Tracking accuracy
0.1 ° -2 ° (Adjustable) Azimuth Tracking Range ±45° System warranty
3 years Weight per set 150kgs -250kgs Land area(1 Mw)
20000~30000m2
